Flight #42 - 2025a

The 42nd flight of the Project: Traveler group will again be launched from the Hutchinson Municipal Airport's in conjunction with the Hutchinson Regional's 2025 Open House.

The payloads will consist of two of the newest ptSolar lightweight trackers, and optionally backed up by a legacy ArduinoTrack tracker, depending on the availability of a chase team.

The ptSolar is the next generation of Project: Traveler tracker, designed for light-weight pico balloon operation. It is largely based on technologies used in the prior generation trackers, but this will be a maiden voyage for this tracker design and firmware.

Flight Parameters

Launch Date/Time

Saturday May 3, 2025 at 10:30am (15:30Z)



Alternative Date

n/a



Launch Site

Hutchinson Municipal Airport (38.07N, 97.87W)



Capsule 1

(Track)

Tracker: Solar-powered ptSolar Tracker transmitter signing W0ZC-1

  • 500mW
  • 144.39MHz (fix freq.)
  • Courtesy Tone

Sensors: n/a

Beaconing: Delay

  • Beacons every 35 seconds, depending on solar charge.
  • GPS Enabled at 3.7V
  • Transmit Enabled at 3.9V
  • Path is disabled above 2000m MSL.

Cameras

  • n/a

0.02kg

Capsule 2

(Track)

Tracker: Battery-powered ptSolar Tracker transmitter signing W0ZC-2

  • 500mW
  • 144.39MHz
  • No Courtesy Tone

Sensors: n/a

Beaconing: Delay

  • Beacons every 50 seconds
  • GPS Enabled at 3.7V
  • Transmit Enabled at 3.9V
  • Path is disabled above 2000m MSL.

Cameras: n/a

 0.07kg

Capsule 3

(Track)

Tracker: ArduinoTrack Tracker signing W0ZC-11

  • 300mW
  • 144.39MHz

Sensors: n/a

Beaconing: Delay

  • Beacons every 55 seconds
  • Path is disabled above 2000m MSL.

Cameras

  • n/a

0.15kg (optional, depending on recovery team)

Recovery / Misc

Parachute and misc rigging. If we fly the ArduinoTrack, then we'll fly the standard RocketMan parachute. If it's just the two ptSolars, then we'll use a streamer-style recovery system. Both weight approximately the same.

0.16kg

Flight Weight

Total neck weight on balloon.

0.31kg

Balloon / Gas

1200g Kaymont with 2.67cu meters of Hydrogen.

  • Neck Lift: 1.5kg
  • Net Lift: 1.2g



Estimated Burst Altitude

35,000m MSL (114,830')



Estimated Ascent Rate

5.6m/s (1,115'/min)



Estimated Descent Rate

4.0m/s (780'/min) velocity at touch-down.



Chase Frequencies

446.100MHz



NOTAM Filed

High Altitude Balloon from HUT VOR on radial 038, XXX bound reaching Flight Level 600 from May 3 at 1530Z to May 3 2000Z.
